| Printer Specifications | T453B |
| Resolution | 203 DPI |
| Print Method | Thermal Transfer / Direct Thermal |
| Memory | 32 MB RAM / 16 MB Flash |
| Max.Print Width | 4.09 in./ 104 mm |
| Max.Print Speed | Up to 6 ips (152 mm/s) |
| Media Sensors | Movable Black Mark Sensor / Movable Gap Sensor |
| Emulation | TSPL, ZPL, EPL, DPL |
| Interface | USB, USB+Serial, USB+Ethernet, USB+Serial+Ethernet, Optional Wireless Connectivity: Bluetooth / Wi-Fi |
| Others | Optional RTC, Standard SD Card Slot |
| Media and Ribbon Characteristics |
| Media Length | 0.39 in.~70 in.(10 mm ~ 1778 mm) |
| Media Width | 1 in. ~ 4.6 in. (25.4 mm ~ 118 mm) |
| Media Roll Size | 5 in. / 127 mm Outer Diameter, Core Inner Diameter: 1 in. (25.4 mm) |
| Media Thickness | 0.0023 in. (0.06 mm) Min.; 0.01 in. (0.254 mm) Max. |
| Media Types | Continuous, Gap, Black mark, Fan~fold, Perforated Media |
| Ribbon Outside Diameter | 2.63 in. / 67 mm |
| Max. Ribbon Length | 300 Meters (984 ft.) |
| Ribbon Width | 1 in. ~ 4.3 in. (25.4 mm ~ 110 mm) |
| Ribbon Core I.D. | 1 in. / 25.4 mm |
| Environment Condition |
| Operating Temp. | 5 ~ 40℃(41~104℉) |
| Storage Temp. | -40 ~ 60℃(-40~140℉) |
| Operating Humidity | 25 ~ 85% Non-Condensing |
| Storage Humidity | 10 ~ 90% Non-Condensing |
| Fonts/Graphics/Symbologies |
| 1D Bar Codes | Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar,Interleaved 2 of 5, EAN-8,EAN-13,EAN-128, UPC-A, UPC-E,EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11 |
| 2D Bar Codes | PDF-417, Maxicode, DataMatrix, QR code, Aztec |
| Fonts and Graphics | Font 0 ~ Font 8 |
| Software |
| Driver | Windows /Linux /Mac / Android / Chrome OS |
| SDK | Windows/Linux / Android /iOS |
| Software | Bartender UltraLite / Mobile Label Design App |
| Accessories |
| Standard Accessories | Power Adapter, Power Cord, USB Cable, User Manual, CD , Label spindle, Fixing tab, Fixing tab, Ribbon spindle, Ribbon for test, Ribbon paper core, label roll for test |
| Factory Installed Options | Bluetooth Module, Wi-Fi Module, Peel-off Module, Cutter Module |
| User Options | 8" External Paper Roll Holder |
| Product Warranty |
| Printhead life | The earlier of 30 km usage or 1 year |
| Platen roller life | The earlier of 30 km usage or 1 year |
| Printer Warranty | 1 Year |
| Physical Characteristics |
| Dimension | 282 mm × 232 mm × 171 mm (D × W × H) |
| Weight | 2.56 Kg |
